Mackie SRM215 V-Class 15″ 2000W High-Performance Powered Loudspeaker

Building upon the success of the SRM legacy, the latest Mackie SRM215 V-Class delivers 2000W of output, clarity, and simplicity in a 15″ design that can be used as a main or monitor and is well suited for DJs, clubs, bars, houses of worship, and rental companies.

WHERE TO BUY
Speak To An Expert
SKU SRM215 V-CLASS Categories , Tag Brand:

Specs

Configuration Active 2-Way
Enclosure Type Bass-Reflex Loudspeaker/Floor Monitor
Total Power Capacity 2000 W Peak
Amplifier Class Class-D
MF Driver None
MF Voice Coil None
LF Driver 1 x 15″ / 381 mm Woofer
Frequency Response 40 Hz to 20 kHz
Maximum SPL 136 dB SPL (Peak)
Coverage Angle 60° H x 40° V
Protections Crossover Overload, Infrasonic, Output Limiter, Thermal, Transducer Overdrive, Ultrasonic
Audio I/O 1 x Combo XLR-1/4″ TRS Female Balanced/Unbalanced Mic/Line Input
1 x Combo XLR-1/4″ TRS Female Balanced/Unbalanced Mic/Line/Hi-Z Input
1 x 1/8″ / 3.5 mm TRS Female Unbalanced Aux Input
2 x XLR 3-Pin Male Balanced Line Output
1 x XLR 3-Pin Male Balanced Mix Output
Wireless Connectivity Bluetooth
Wireless Range 328.1′ / 100 m
Filters None
Alignment Delay 89.3 ms
Digital Signal Processing Delay, Reverb, User Settings, Venue Settings, Voicing Modes
AC Input Power 110 to 240 VAC, 50 / 60 Hz
AC Power Connector 1 x IEC Input
Mounting 1 x 1.38″ / 35 mm Pole Socket (Dual Angle, Bottom)
Handles 1 x Each Side
1 x Top
Dimensions 28.8 x 15.4 x 17.6″ / 731.5 x 391.2 x 447 mm
Weight 48.9 lb / 22.2 kg
Package Weight 55.8 lb
Box Dimensions (LxWxH) 32.2 x 20.85 x 18.5″

The powerful system is paired with a custom Sym-X horn with a premium polymer HF driver to provide a smooth and consistent mid- and high-frequency response, while the heavy-duty woofer provides an accurate and consistent transient response for bass that never gets muddy. Proprietary Advanced Impulse DSP tuning and Intelligent Bass Management to deliver a consistent listening experience to your whole audience even at extreme volumes. The integrated digital mixer has a full-color display and features Bluetooth streaming, powerful processing, plus complete wireless control via the SRM Connect app.

Professional 2000W Class-D Amplifier

  • Mackie’s most advanced amplifier platform to date, delivering remarkable stability, headroom, and audio fidelity
  • High SPL
  • Reliability and rock-solid operation can withstand the most demanding applications
  • Universal power supply (100-240 VAC) with Power Factor Correction for stable operation even with unstable AC power

Advanced Impulse DSP / Proprietary Acoustic Tuning

  • Clear sound across the entire dispersion zone means the whole room is the sweet spot
  • Precision crossover and transducer time-alignment ensures balanced and accurate sound

Intelligent Bass Management

  • Proprietary LF management technology maintains tonal balance and output level when operating at very high volumes while keeping the bass tight and punchy

Wireless Link

  • Wirelessly link two SRM | V-Class speakers together for music streaming applications plus complete control over both speakers
  • Uses latest Bluetooth technology allows up to 328′ of range between linked speakers
  • Stereo or dual-zone linking modes allow discrete control over the inputs and outputs of the entire system across two rooms or zones
  • Create a clean setup in minutes

Custom Sym-X Horn

  • Allows for total efficiency from the HF transducer minimizing distortion and increasing output
  • Creates a perfectly symmetrical, flat response at the crossover point for exceptionally smooth midrange
  • The horn-loading frequency is set below the drivers’ LF capability allowing for maximum efficiency and optimal performance at the crossover point

High-Performance Custom Transducers

  • Large, powerful magnets partner with robust motors, voice coils, and spiders to provide the highest possible efficiency and transient accuracy
  • Additional cooling vents surrounding the specially designed voice coil plus directional cabinet porting ensures maximum heat dispersion and reliability
  • Premium polymer high-frequency driver provides the flattest possible response for incredibly smooth highs that sound natural and balanced

Transparent System Limiting and Protection

  • Dedicated processing module monitors and protects the amplifier in real time
  • Sound quality and tonal balance is maintained even under heavy limiting
  • Utilizing powerful multiband compression, the amplifier can target specific frequency ranges to prevent the system from being overloaded rather than turn everything down at the expense of overall output
  • Input limiting keeps your source signal in check so if your sending audio is a bit too hot, the speaker will cool it down

SRM Mix Control Built-In 4-Channel Digital Mixer with Bluetooth

  • Dual independent channels that support mic, line, and instrument signals
  • Dedicated 3.5mm stereo aux channel
  • Stream music from any Bluetooth enabled device
  • High-contrast, full-color display for easy single-knob access to mixer and processing
  • Adjust channel levels and EQ
  • Application and venue specific voicing modes
  • Alignment delay up to 100′
  • Save and recall up to 10 user presets
  • Screensaver plus dimmer and contrast control
  • System lock with 4-digit passcode
  • Change front LED function: green, white, off, signal present, multi (cycle through colors)

Complete Wireless Control via the SRM Connect App

  • The SRM Connect app gives you access to all adjustments and settings including EQ, levels, and presets

Versatile Configuration Options

  • Dual-angled cabinet design allows for use as a high-performance floor monitor
  • Dual-angle pole mount provides optimal coverage and minimal reflections in most venues. The 7-degree downward tilt is perfect for when the speakers are on elevated stages
